Este sistema ATM350S de micrófono para instrumento de Audio Technica Incluye:

• Micrófono ATM350a
• Módulo de alimentación Phantom in-line AT8543
• Soporte para Montaje en Superficie AT8491S
• Flexo UniMount Largo AT8490L
• Audio Technica Sistema 10 Inalámbrico Body Pack ATW-1101
• Estuche de Transporte

Micrófono de condensador cardioide para instrumentos con componentes UniMount®

Con una respuesta limpia, clara y bien balanceada incluso en aplicaciones con niveles de presión sonora elevados, el micrófono de condensador cardioide para instrumentos ATM350a viene en seis sistemas especialmente diseñados que ofrecen soluciones de montaje discretas y robustas para una amplia gama de instrumentos, como instrumentos de viento-madera, instrumentos de cuerda, instrumentos de viento-metal, baterías y pianos.

Los ocho sistemas de microfonía ATM350a combinan el micrófono para instrumentos con componentes UniMount® exclusivos, ofreciendo a ingenieros de sonido y músicos una gran cantidad de opciones de montaje fiables tanto en el escenario como en el estudio. Las opciones incluyen un robusto soporte para batería, un soporte magnético para piano completamente nuevo, una pinza de sujeción universal renovada, un soporte para instrumentos de viento-madera y dos flexos robustos (5 y 9 pulgadas) que pueden fijarse a cualquiera de los soportes.

Este robusto flexo UniMount® (largo) proporciona un soporte sólido pero flexible para el micrófono cardioide de condensador para instrumento ATM350a, de forma que el usuario puede posicionar el micrófono en la posición que desee, pudiendo confiar en todo momento que permanecerá de forma estable en la posición deseada. Un filtro antiviento de espuma que rodea totalmente el micrófono. El AT8490 puede ser utilizado con el soporte universal de tipo pinza AT8491U, el soporte magnético para piano AT8491P, soporte para batería AT8491D y soporte para instrumentos de viento AT8491W.

• Flexo 9‘‘
• Flexible posicionamiento del micrófono
• Excelente durabilidad y estabilidad
• Ideal para instrumentos más grandes

Obtenga acceso inalámbrico digital diseñado para disponer a los músicos y presentadores con estos sistemas digitales de alta fidelidad, con una operación avanzada de 24 bits en el rango de 2.4 GHz. El sistema 10 es perfecto para la dirección pública, las casas de alquiler de A/V, iglesias y templos, televisión y interferencia de DTV.

 Con sólo un botón, el sistema 10 ATW-1101 determina y ajusta automáticamente la mejor frecuencia disponible (canal abierto). Es útil cuando se emplean múltiples sistemas inalámbricos, evitando así la interferencia y la intermodulación. Cuando hay necesidad de utilizar múltiples sistemas inalámbricos simultáneamente, hasta ocho canales pueden ser utilizados juntos sin problemas de coordinación de frecuencia o problemas de selección de grupo. Una pantalla de información LCD fácil de leer proporciona indicaciones visuales prácticas de los ajustes y el estado de funcionamiento.

CARACTERÍSTICAS

• Sistema

• Canales Simultáneos: 8
• Analógico/Digital: Digital
• Frecuencia de Respuesta: 2.4GHz
• Rango de Operación: Linea de Vision
• Frecuencia de Respuesta: 20Hz-20kHz
• Micrófono incluido: Si
• Selección de Canales: Auto
• Cable de instrumento: Connector 1 1/4"
• Cable de instrumento: Connector 2 Hirose 4-pin

• Transmisor Factor de Forma
• Rango Dinámico: 109dB (A )
• Tipo de Antena: Fijo 2 x AA
• Tipo de batería: 7 hours
• Connector: Hirose 4-pin
• Dimensiones: 2.76" x 4.21" x 0.98"
• Peso: 0.22 lbs.

• Receptor
• Tipo de Antena: Fijo
• Pantalla del Panel Frontal: Si
• Displays: LED
• Tipo Tablero: Table Top
• Salidas: 1 x XLR, 1 x 1/4"
• Dimensiones: 7.48" x 1.82" x 5.06"
• Peso: 0.64 lbs.

Soporte para Montaje en Superficie AT8491S

El soporte para montaje en superficie AT8491S le permite utilizar un micro de condensador cardioide para instrumentos ATM350a y el correspondiente soporte tipo flexo con acordeones y otros instrumentos con superficies de montaje complicadas. El soporte dentado puede fijarse de manera permanente mediante el tornillo de acordeón y la almohadilla de silicona adhesiva incluida, o de forma temporal con las almohadillas de cinta adhesivas incluidas. También se incluye un películas protectora para evita que se dañe el acabado del instrumento. El soporte incluye una toma con tornillo de bloqueo para sujetar con seguridad un soporte tipo flexo AT8490 de 5 pulgadas o AT8490L de 9 pulgadas.

Módulo de alimentación Phantom in-line AT8543

• Modulo de alimentación para micrófono de instrumento ATM350a
• Dispone de supresión de graves seleccionable
• Entrada a través de HRS4M
• Salida a través de XLRM 3-pin

El sistema 9 de Audio-Technica es un sistema inalámbrico ágil de una frecuencia de cuatro-canales diseñado para dar una presentación sólida con configuración sencilla y una calidad de sonido clara y natural. Presentando un estilo elegante, apilable, y contemporáneo, el sistema 9 está disponible en modo manual, con diadema, de guitarra, lavalier, y configuraciones body-pack. El sistema ofrece cuatro canales VHF compatibles con el usuario que pueden ser cambiados (169.505, 170.245, 171.045, and 171.905 MHz).

Cada configuración del Sistema 9 incluye el receptor ATW-R900 y un transmisor de cuerpo-paquete o un micrófono / transmisor de mano. El ATW-R900 es un receptor de un solo canal de diversidad, con diseño avanzado de antena dipolo para un rango de operación extendido, lo que mejora el funcionamiento proporcionando es un factor terrestre, además del elemento de señal usual. El ATW-R900 también ofrece control de volumen junto con las luces indicadoras AF Peak, RF y Power.

• Fácil de operar y calidad de sonido clara y natural
• 4 canales VHF seleccionables coordinados con frecuencia
• Conectores de salida balanceados XLR y sin-balancear 1/4" permiten el uso con una variedad de equipo de audio
• Presentaciones confiables y construcción duradera
• Sistema de antena dipolo para rango de operación extendido

OVERALL SYSTEM SPECIFICATIONS

Operating Frequencies: VHF highband, 169 MHz to 172 MHz
Modulation Mode: FM
Maximum Deviation: +/-10 kHz
Dynamic Range: >/=90 dB (A-weighted), typical
Total Harmonic Distortion: <1% (at 1 kHz, +/-10 kHz deviation)
Operating Range: 200' (60 m) typical
Open range environment with no interfering signals
Operating Temperature Range: 40° F (4° C) to 110° F (43° C)
Battery performance may be reduced at very low temperatures
Frequency Response: 80 Hz to 13 kHz
Maximum Simultaneous Use (Recommended): 200' minimum

RECEIVER SPECIFICATIONS
Receiving System: Non-diversity, single-channel, dual antenna system
Image Rejection: 50 dB minimum
RF Sensitivity: 20 dBuV at 60 dB S/N ratio (50 ohms termination)
Audio Output: Nominal Output Level
XLR, balanced: 350 mV (1 kHz modulation, 10 kHz deviation, 100k ohm load)
1/4" (6.3 mm), unbalanced: 700 mV (1 kHz modulation, 10 kHz deviation, 100k ohm load)
Power Supply: 100-240V AC (50/60 Hz) to 12V DC .5A (center positive) switched mode external power supply
Operating Temperature Range: 40° F (4° C) to 110° F (43° C)
Dimensions: 7.48" (190.0 mm) W x 1.82" (46.2 mm) H x 5.06" (128.5 mm) D
Net Weight: 12.0 oz (337 grams)
Accessory Included: Power supply

BODY-PACK TRANSMITTER SPECIFICATIONS
RF Power Output: 10 mW
Spurious Emissions: Following federal and national regulations
Input Connections: Four-pin Locking Connector
Pin 1: GND
Pin 2: INST INPUT
Pin 3: MIC INPUT
Pin 4: DC BIAS +9V
Batteries: Two 1.5V AA
not included
Battery Life: 8 hours (alkaline)
Depending on battery type and use pattern
Dimensions: 2.76" (70.2 mm) W x 4.08" (103.7 mm) H x 0.98" (24.9 mm) D
Net Weight: 2.8 oz (80.0 grams)
without batteries

HANDHELD TRANSMITTER SPECIFICATIONS
RF Power Output: 10 mW
Spurious Emissions: Following federal and national regulations
Batteries: Two 1.5V AA
not included
Battery Life: 8 hours (alkaline)
Depending on battery type and use pattern
Dimensions: 9.91" (251.8 mm) long,
2.11" (53.5 mm) diameter
Net Weight: 9.2 oz (260 grams)
without batteries
Accessory Included: AT8456a Quiet-Flex™ stand clamp

•  Audio Technica System 901 Microphone Transmitter and Bodypack: ATW-901A/G
• Audio Technica ATM350UCW Cardioid Condenser Clip-On Instrument Microphone: ATM350UCW
• Audio Technica AT8490L Long UniMount for ATM350: AT8490L
• Audio Technica AT8491S Accordion Surface Mount: AT8491S

Audio-Technica's System 9 is a four-channel frequency-agile wireless system designed to provide rock-solid performance along with easy setup and clear, natural sound quality. Featuring sleek, stackable, contemporary styling, System 9 is available in handheld, headworn, guitar, lavalier and body-pack configurations. The system offers four compatible user-switchable VHF channels (169.505, 170.245, 171.045, and 171.905 MHz).

Each System 9 configuration includes the ATW-R900a receiver and either a body-pack transmitter or handheld microphone/transmitter. The ATW-R900a is a non-diversity, single-channel receiver with advanced dipole antenna design for extended operating range, which improves operation by providing a ground element in addition to the usual signal element. The ATW-R900a also offers volume control along with AF Peak, RF and Power indicator lights.

• Easy to use, with clear and natural sound quality
• 4 frequency-coordinated selectable VHF channels
• 1/4" balanced and unbalanced XLR output connectors compatible with a wide variety of audio adapters
• Reliable performance and rugged manufacturing
• Advanced dipole antenna system to increase operating range

CHARACTERISTICS

GENERAL SYSTEN SPECIFICATIONS

• Operating Frequencies: VHF high band, 169 to 172 MHz
• Modulation Mode: FM
• Maximum Deviation: +/- 10 kHz
• Dynamic range: > / = 90 dB (Weighting A), typical
• Total harmonic disturbance: <1% (at 1 kHz, deviation of +/- 10 kHz)
• Total harmonic distortion: <1% (at 1 kHz, deviation of +/- 10 kHz)
• Operating Range: 200 '(60 m), typical (Open environment without signal interference)
• Operating Temperature Range: 40 ° F (4 ° C) to 110 ° F (43 ° C) (Battery and LCD display performance may be affected by very low temperatures.)
• Frequency Response: 80 Hz to 13 kHz
• Maximum Simultaneous Use (Recommended): 200 'minimum

RECEIVER SPECIFICATIONS

• Receiver System: Dual antenna system, without diversity and a single channel Image rejection: 50 dB minimum
• RF sensitivity: 20 dBuV at 60 dB S / N (50 ohm termination)
• Audio Output: Nominal output level; XLR, balanced: 350 mV (1 kHz modulation, 10 kHz deviation, 100k ohm load); 1/4 "(6.3 mm), unbalanced: 700 mV (1 kHz modulation, 10 kHz deviation, 100k ohm load)
• Power Supply: 100-240 V AC (50/60 Hz) at 12 DC. 5 A (positive center) switched mode, external power supply
• Dimensions:0 mm (7.48 ") wide x 46.2 mm (1.82") high x 128.5 mm (5.06 ") deep
• Net Weight:0 oz (337 g)
• Accessory Included: Power Supply

BODY PACK TRANSMITTER SPECIFICATIONS

• RF Power Output: 10 mW
• False Emissions: According to federal and national regulations
• Input Connections: Connector with four pin anchor; Pin 1: Earth; Pin 2:
• Instrument input; Pin 3: Microphone input; Pin 4: DC + 9V polarization
• Batteries: Two 1.5V AA type, not included
• Battery Life: 8 hours (alkaline) (Depending on the type of battery and usage pattern)
• Dimensions:2 mm (2.76 ") wide x 24.9 mm (0.98") deep x 103.7 mm (4.08 ") high
• Net Weight:8 oz (80 g), without batteries

HANDHELD TRANSMITTER SPECIFICATIONS

• RF Power Output: 10 mW
• False Emissions: According to federal and national regulations
• Batteries: Two 1.5V AA type, not included
• Battery Life: 8 hours (alkaline) (Depending on the type of battery and usage pattern)
• Dimensions:91 "(251.8mm) long, 2.11" (53.5mm) diameter
• Net Weight:2 oz (260 g), without batteries
• Accessory Included: Quiet-Flex ™ AT8456a Pedestal Clamp

Designed for wind-metal instruments, saxophone and others, the UniMount® ATM350U mounting system offers you the tools to act with confidence. The system includes the ATM350a cardioid condenser microphone, a microphone that supports high levels of sound pressure, and offers a clear and well-balanced response from any instrument. When combined with the AT8491U universal clamp and the flexible, rugged AT8490 5-inch gooseneck included, the mic can be securely attached to the instrument strap and positioned to stay where you want it - the gooseneck will remain static regardless of where the instrument moves when playing.

The cardioid polar pattern of the microphone isolates the instrument by reducing the pickup of side and rear sounds, and the switchable 80 Hz high-pass filter of the in-line power module helps control unwanted low-frequency noise. The system also includes a violin holder (AT8468) with Velcro fastener and a carrying case.

• Small microphone that goes virtually unnoticed
• Clear, bright and well-balanced response, even at high sound pressure levels
• Cardioid polar pattern that reduces the capture of lateral and posterior sounds, improving the isolation of the desired sound source
• UniMount® AT8491U Universal Clamp that securely attaches to the instrument's mail and provides excellent anti-vibration protection for the microphone
• Robust UniMount® AT8490 5-inch gooseneck that stays rigid at all times, allowing the microphone to position accurately even during the most aggressive performances
• In-line power module equipped with a switchable 80 Hz high-pass filter that controls unwanted ambient noise 4-pin lockable connector for use with cW style body-pack transmitters
• Interchangeable elements available for hypercardioid and omnidirectional polar patterns
• Violin support with Velcro fastener is included as an additional mounting option

CHARACTERISTICS

• ELEMENT: Fixed-charge back plate, permanently polarized condenser
• POLAR PATTERN: Cardioid
• FREQUENCY RESPONSE: 40 – 20,000 Hz
• LOW FREQUENCY ROLL-OFF: 80 Hz, 12 dB/octave
• OPEN CIRCUIT SENSITIVITY: –49 dB (3.5 mV) re 1V at 1 Pa
• IMPEDANCE: 200 ohms
• MAXIMUM INPUT SOUND LEVEL: 159 dB SPL, 1 kHz at 1% T.H.D.
• DYNAMIC RANGE (typical): 130 dB, 1 kHz at Max SPL
• SIGNAL-TO-NOISE RATIO: 65 dB, 1 kHz at 1 Pa
• PHANTOM POWER REQUIREMENTS: 11– 52V DC, 3.5 mA typical SWITCH Flat, roll-off
• WEIGHT (MICROPHONE):5 g (0.5 oz)
• WEIGHT (POWER MODULE): 90 g (3.2 oz)
• DIMENSIONS (MICROPHONE):8 mm (1.49'') long, 12.2 mm (0.48'') maximum body diameter
• DIMENSIONS (POWER MODULE): 92 mm (3.62") long, 18.9 mm (0.74") diameter
• OUTPUT CONNECTOR (POWER MODULE): Integral 3-pin XLRM-type
• CABLE:0 m (13.1') long (permanently attached to microphone), 3.2 mm (0.13") diameter, 2-conductor shielded cable with HIROSE HR10-type connector
• OPTIONAL INTERCHANGEABLE ELEMENTS: UE-H hypercardioid (100°) UE-O omnidirectional (360°)
• ACCESSORIES FURNISHED: ATM350a cardioid condenser microphone; AT8543 power module; AT8491U UniMount® universal clip-on mount; AT8490 UniMount® 5" gooseneck; AT8468 violin mount (hook-and-loop fastener); protective carrying case
• AUDIO-TECHNICA CASE STYLE: M36

This rugged UniMount® 9" gooseneck provides strong yet flexible support for the ATM350a Cardioid Condenser Instrument Microphone, so you can position the mic where you want it and be confident that it will stay there. An integral foam windscreen entirely surrounds the microphone. The AT8490L can be used with the AT8491U Universal Clip-on Mount, AT8491P Magnetic Piano Mount, AT8491D Drum Mount and AT8491W Woodwind Mount.

CHARACTERISTICS

• 9” long
• Flexible microphone positioning
• Excellent durability and stability
• Ideal for larger instruments

The AT8491S surface mount allows you to use an ATM350a Cardioid Condenser Instrument Mic and accompanying gooseneck with accordions and other instruments with challenging mounting surfaces. The notched mount can be attached permanently using the accordion’s grille screw and the included adhesive silicon pad, or it can be attached temporarily using the included fastener tape pads. A transparent protective film is also included to prevent damage to the instrument’s finish. Mount includes a socket with locking screw to securely hold an AT8490 5" or AT8490L 9" gooseneck.

CHARACTERISTICS

• Fits Audio-Technica Case Style(s): M36
• Designed for accordions and other difficult applications
• Extender mounting accessories included
• AT8475 surface mount kit included

The AT2020PK vocal microphone pack is designed for streamers, podcasters, and other content creators who need a versatile, easy-to-install, easy-to-adjust boom microphone setup. The pack includes an AT2020 cardioid condenser microphone, a pair of ATH-M20x professional monitor headphones and a studio boom arm threaded with a XLR cable.

The adjustable studio boom arm clamps securely to desks, tables and other flat surfaces up to 55 mm (2.2") thick. The boom is threaded internally with an XLR cable for a clean appearance and unhindered operation. Offering full 360° rotation and adjustable, spring-stabilized joints, the boom arm repositions quickly for optimal mic placement.

The rugged AT2020 side-address studio condenser microphone features a low-mass diaphragm that is custom-engineered for extended frequency response and superior transient response for excellent vocal reproduction. The microphone offers a wide dynamic range and handles high SPLs with ease. Its analog XLR output connects easily to a digital converter or mixer.

Rounding out the pack are the ATH-M20x pro headphones, part of Audio-Technica’s critically acclaimed M-Series line. With 40 mm drivers tuned for enhanced low-frequency performance and comfortable, sound-isolating earpads, the M20x headphones are perfect for long monitoring sessions.

AT2020 Cardioid Condenser Microphone

• The price/performance standard in side-address studio condenser microphone technology
• Ideal for vocal pickup
• High SPL handling and wide dynamic range provide unmatched versatility
• Custom-engineered low-mass diaphragm provides extended frequency response and superior transient response
• Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
• Pivoting, threaded stand mount attaches securely for easy and precise placement of the microphone

ATH-M20x Professional Monitor Headphones

• Advanced build quality and engineering
• 40 mm drivers with rare earth magnets and copper-clad aluminum wire voice coils
• Tuned for enhanced low-frequency performance
• Circumaural design contours around the ears for excellent sound isolation in loud environments
• Convenient single-side cable exit

Adjustable Studio Boom Arm

• Full 360° rotation
• Adjustable, spring-stabilized joints with thumbscrews for easy repositioning of the microphone
• Clamps securely to desks, tables and other flat surfaces up to 55 mm (2.2") thick
• Included XLR cable (XLRF to XLRM) extends 3 m (10') from the base of the boom arm
• Internal cable management for clean desk appearance

ATH-M20x Headphones Specifications
Type: Closed-back dynamic
Driver Diameter: 40 mm
Magnet: Neodymium
Voice Coil: Copper-clad aluminum wire
Frequency Response: 15 – 20,000 Hz
Maximum Input Power: 700 mW at 1 kHz
Sensitivity: 96 dB
Impedance: 47 ohms
Weight: 190 g (6.7 oz), without cable and connector
Cable: 3.0 m (9.8'), straight, left-side exit
Accessories Included: 6.3 mm (1/4") snap-on adapter
